Appearance size (L/W/H)：2.0*1.7*0.8mm
Working temperature：-40℃ ~ + 85℃
Reflow soldering: The number of reflow soldering should not exceed two times
EIA specification standard packaging
Environmentally friendly products, in line with RoHS requirements
Suitable for automatic placement machine
Suitable for infrared reflow soldering process
| Schematic | Product Model | Brand | Color | Package | Brightness(mcd) | Test ConditionsIF (mA) | Voltage(v) | Package Size(mm) | Wavelength/Color Temperature(nm/k) | Specifications |
|
JM-0807RGB Symphony-5mA |
Jingmeng |
Multicolor |
0807RGB Symphony |
75-130 200-300 50-100 |
IF=5mA |
1.7-2.2 2.6-3.3 2.6-3.3 |
2.0*1.7*0.8 |
R-G-B |
 |
|
|
JM-0807RGB Symphony-12mA |
Jingmeng |
Multicolor |
0807RGB Symphony |
100-300 280-440 75-130 |
IF=12mA |
1.7-2.2 2.6-3.3 2.6-3.3 |
2.0*1.7*0.8 |
R-G-B |
|
